| Brand Name : | JIGUO |
| Model Number : | MY-1060HIGH |
| Certification : | CE |
| Price : | 50000 dollors--100000 dollors |
| Payment Terms : | T/T |
| Supply Ability : | 5 set |
| Delivery Time : | 45 days |
| Model | MY-1060High |
| Max.paper size | 1070×770mm |
| Min.paper size | 380×340mm |
| Max.cutting size | 1040×750mm |
| Max.die cutting speed | 7000s/h |
| Max.Sheet thickness | Corrugated board: ≤4mm Cardboard:0.1-4mm |
| Die Cutting Accurate | ±0.1mm |
| Min. Gripper Edge | 8mm |
| Max. Feeding Pile | 1600mm |
| Max. Delivery Pile | 1400mm |
| Max.pressure | 600 Tons |
| Total power | 24 Kw |
| Net weight | 19.8 Tons |
| Air requirement | 0.8Mpa,＞0.36m³/min |
| Overall dimension | 6700×4100×2350 |
|
|
